– for charging of electronic devices via a standard USB port (also
compatible with Apple devices)
– enables charging of two devices simultaneously
– power supply: 230V~ 50Hz
– stand-by power consumption: 50 mW at 230V~
– nominal output voltage: 5 VDC (±5%) SELV
– output ripple voltage: 150 mV
– nominal output current: 1 A (1 x 1.000 mA or 2 x 500 mA) (±10%)
– efficiency: greater than 67%
– IP protection class: IP20, indoor use only
– screw contacts: max. 2.5 mm2
– in accordance with EN 60950-1 and EMC directive
– an appropriate external disconnect device needs to be considered as
part of installation
