– USB 2.0 socket type A
– screw contacts, raster 5 mm, 1,5 mm2, 1x2P + 1x3P
– wiring:
PIN 1 – VCC (+5V, red wire)
PIN 2 – Data – (white wire)
PIN 3 – Data + (green wire)
PIN 4 – GND – ground (black wire)
S – shield
– in accordance with directive 2011/95/EU (RoHS2)
